Grinding Media Filling Calculation Formula

Release time：2021-10-12

Calculation method of filling rate of grinding body

The filling rate of the grinding body can be calculated according to the inner diameter of the grinding machine and the distance from the surface of the grinding body to the highest point of the lining of the grinding machine. If the lining plate is of a special shape, such as corrugated or stepped type, it must be reasonably corrected and the average value should be used.

Filling rate can be simplified as :=1.068-1.164 (H/D)

H is the distance from the grinding surface to the highest point of the liner

D is the effective inner diameter of the mill

Measurement of top height:

The formula for calculating the filling rate of grinding body is:

=3 /360-sin 3 /2 T

(1)

Is the filling rate of abrasive body, %

β is the central Angle of the ball surface to the mill center, '.

Height from the surface of the grinding body to the top of the grinding inside H:

H = (1/2) D + H = (1/2) + D (1/2) Dcos (beta / 2)

(2)H is the height from the surface of the grinding body to the top of the grinding inside, m

D is the effective inner diameter of the mill,

H is the height from the surface of the grinding body to the center of the mill, m

Arrange (2) into:

Cosine of B over 2 is equal to 2 times H over D one

(3)

It can be seen from Equation (3) that, after H value is measured, D is a known number for a certain mill, and the β value can be calculated. According to Equation (1), the filling rate, H/D and, can be calculated
